DC COMBINER BOXES
Our combiner boxes are known for a clean and well thought out design that take multiple source circuits and combines them into a single output.
PRODUCT FEATURES
SAFETY
FEATURES
Keep your team safe and speed up O&M
IR WINDOW
- Viewing window into the combiner box that allows for an IR temperature measurement prior to opening the enclosure
- Ensures a safe environment for operators by avoiding exposure to live wires that could have a short circuit
TESTING PORTS
- A test port in the door of the combiner box that allows the operator to confirm continuity and switch position using a handheld multi-meter or similar tool
- Safely test voltage without opening the box or exposing operators to live circuits without knowing if the disconnect switch is closed or live
AVAILABLE OPTIONS
- Mechanical Lugs
- Provisions for compression lugs
- Isolating / grounded / floating configurations
- Touch safe protective cover
- Custom layouts
- Pre-terminated input conductors
- 10kA SCCR and greater
- Battery and energy storage
- Transient surge suppression
- Breather and drain vents
- Pad-lockable enclosures
- Lockout / tagout provision
SPECIFICATIONS
*Other options available upon request. Please note dimensions and weight may vary for any custom solutions. Contact us for details.
